Model NE-4000 Multi-Phaser™
Publication #1200-01 35 09/05/14
=>
Rate Data Functions
When a Phase’s function is set to a “Rate Data Function”, use the ‘RAT’, ‘VOL’, and ‘DIR’
commands to setup the pumping parameters.
RAT Pumping rate. ‘RATE’
FIL Fill syringe to dispensed volume. ‘FILL’
INC Increment rate. ‘INCR’
DEC Decrement rate. ‘DECR’
Non-Rate Control Functions
STP Stop pump. ‘STOP’
PAS Pauses pumping for ‘nn’ seconds. ‘PS:nn’
PAS Pauses pumping for 'n.n' seconds. 'PS:n.n'
PRI Sub-Program Selection Input. 'Pr:In'
PRL Sub-Program Start Label definition. 'Pr:nn'
LPS Loop starting Phase. ‘LP:ST’
LPE Loop end Phase. ‘LP:EN’
LOP Loop to previous loop start ‘nn’ times. ‘LP:nn’
JMP Jump to Program Phase. ‘JP:nn’
IF If Program input TTL pin low, jump to Phase. ‘IF:nn’
EVN Set event trigger trap. ‘EV:nn’
EVS Set event square wave trigger trap. 'ES:nn'
EVR Event trigger reset. ‘EV:RS’
CLD Clear total dispense volume. ‘CLR.D’
TRG Override Operational Trigger Default Mode, set to , ‘tr:aa’
BEP Sound short beep. ‘BEEP’
OUT Set programmable output pin. ‘OUT.n’
PUMPING RATE
RAT [ C | I ] [ [ ] ]
Set/query pumping rate.
=> UM = µL/min
MM = mL/min
UH = µL/hr
MH = mL/hr
Applicable only with “Rate Data Functions”.
When setting the pumping rate, if the current Phase’s function is not ‘RATE’, then is not
applicable.
While pumping, the pumping rate can only be set if the current Phase function is ‘RATE’ and the next
Program Phase’s function to be executed is not ‘INCR’ or ‘DECR’. Also, while pumping,
cannot be set.
The new pumping rate will only be stored in non-volatile memory if the Pumping Program is not
operating.
When the pumping rate is queried while pumping, the response will be the current pumping rate and units.
Otherwise, the response will be the rate setting and units, if applicable. With the ‘INCR’ and ‘DECR’
functions, these two responses are not the same.
RAT C [ ]
Allows the Pumping Program to continue after the pumping rate is changed. The RAT C command will
not clear a Paused Pumping state after the rate is changed when the Pumping Program is paused.
Normally, the Pumping Program would re-start from Phase 1 after the rate is changed while paused.
RAT I [ ]
Changes the pumping rate only if the pump is infusing. If the pumping direction is set to withdraw, the
rate change will be ignored.
VOLUME TO BE DISPENSED AND SET VOLUME UNITS
VOL [ | ]
