Sp2S20h paVeMeNT SaW • operaTioN aNd parTS MaNual — reV. #0 (02/17/12) — page 37
hyDrOstatic DrivE assy.
No. parT No. parT NaMe QTY. reMarKS
1 23227-001 SPROCKET, TRANSMISSION 12 TOOTH MACH 1
2 25039 SCREW, SHS 10-24 X 1/4 2
3 19371-023 CHAIN, ROLLER ANSI STANDARD 1
4 10504-035 LINK, CHAIN 1
5 49071 NUT, FLANGED SERRATED PLTD, 5/16-18 2
6 28084-001 SPROCKET, 3548 X 3/4 1
7 0126 KEY, WOODRUFF #9 3
8 28832-001 JACKSHAFT 1
9 23284-001 BEARING, FLANGE .34SQ x 3/4ID 2
10 25354 SCREW, SHS 1/4-20 X 1/2 HOLOKROME 1
11 9091 SCREW, HHFS 5/16-18 X 1 GR5 2
12 28831-001 GEAR, DRIVE 2
13 1578 KEY, WOODRUFF #3 3
14 28087-001 PULLEY, MA60 X 17MM 1
15 25682-001 IDLER PULLEY 1
16 1665 SCREW, HHC 3/8-16 X 2 1
17 10136 WASHER, FLAT SAE 3/8 1
18 10133 NUT, NYLOC 3/8-16 3
19 23303-001 IDLER ARM 1
20 23230-001 SPRING EXT. IDLE 1
21 1284 SCREW, HHC 3/8-16 X 1 1/2 1
22 18574-004 WASHER, BELLEVILLE 3/8 1
23 28864-001 WASHER, FIBRE 1
25 07055-051 V-BELT, TRANSMISSION 4L510 1
26 0130 A SCREW, SHS 1/4 X 20 X 1/4 4
27 60091 LOCTITE, BLUE #242 1
28 1456 NUT, HEX FINISH 3/8-1 1
