Sp2S20h paVeMeNT SaW • operaTioN aNd parTS MaNual — reV. #0 (02/17/12) — page 11
unDEr carriaGE assy.
No. parT No. parT NaMe QTY. reMarKS
1 28777-352 FRAME ASSY. 16”/18”/20” 1
2 28781-002 AXLE, REAR 1
3 28782-351 FRAME, UNDERCARRIAGEE ASSY. 1
4 28086-001 WHEEL, 8 X 2 .75 ROLLER BEARING REAR 2
5 28085-001 WHEEL, 5 X 2 .75 ROLLER BEARING FRONT 2
6 8151 WASHER, FLAT SAE 3/4 8
7 10065-090 BEARING PLAIN 2
8 25181-001 COLLAR, SET 0.75 X 1.50 X .50, SPLIT 4
9 8081 PIN, CLEVIS 1/2 X 2-3/4 1
10 0447 WASHER, FLAT SAE 1/2 4
11 2219 PIN, COTTER 1/8D X 1 1
12 25490 SCREW, SHS 5/16-18 X 3/8 2
13 2621 ZERK, GREASE STR. 1/4-28 1
14 1162 A CAP, ZERK FITTING 1
