Sp2S20h paVeMeNT SaW • operaTioN aNd parTS MaNual — reV. #0 (02/17/12) — page 27
No. parT No. parT NaMe QTY. reMarKS
1 29406-354 BLADE GUARD ASSY., SP20" .....................................1 ........... SAFETY ITEM
2 28729-002 GUARD, SPLASH BLADE 1
3 60021 HOSE, 3/8ID X 5/8 OD BRAIDED PVC “PAC” ..............3 ........... 1 PIECE = 1FT.
4 49048 SCREW, HHFS 1/4-20 X 3/4 GR5 2
5 10024 NUT, NYLOC 1/4-20 2
6 14233-004 FITTING, PLASTIC Y 6 BARB USP 64016 1
7 12694-006 HOSE CLAMP, SPRING TYPE 3/4 O.D. HOSE 2
8 24778-001 FITTING, BRASS 1/2BARB X 3/4F GRDN 1
9 18626-001 SPRING TENSION, GUARD BLADE 2
10 22129-001 PIPE STRAP 3/8 2
11 21168 SCREW, HHC 3/8-16 X 4.75 1
12 0424 SCREW, HHC 1/4-20 X 1 1/4 4
13 0949 NUT, HEX FINISH 1/4-20 PLATED 4
14 0181 B WASHER, LOCK 1/4 MED. 4
15 0948 WASHER, FLAT SAE 1/4 6
16 38274 SCREW, HHFS 3/8-16 X .75 ZINC 1
17 0166 A WASHER, LOCK 3/8 MED. 2
18 10136 WASHER, FLAT SAE 3/8 2
19 28876-001 FITTING, BRASS 3/8BARBx 3/4M GRDN 1
blaDE GuarD assy.
