Sp2S20h paVeMeNT SaW • operaTioN aNd parTS MaNual — reV. #0 (02/17/12) — page 31
battEry assy.
No. parT No. parT NaMe QTY. reMarKS
1 4671 BATTERY, WET GR.U1, GT-X GOLD LA 1
2 28096-001 BRACKET BATTERY 1
3 28095-401 BATTERY HOLD DOWN KIT 425-405 1
4 28093-001 CABLE, BATTERY POS 6GA X 42” RING TONGUE 1
5 28094-001 STRAP, GROUND 1
6 49048 SCREW, HHFS 1/4-20 X 3/4 GR5 2
7 49070 NUT, BATTERY DISCONNECT 1
8 0949 NUT, FLANGED SERRATED PLTD. 1/4-20 X 3/4 2
9 36720 SCREW, HHFS 5/16-18 X 3/4 GR5 3
10 49071 NUT, FLANGED SERRATED PLTD. 5/16-18 3
