Sp2S20h paVeMeNT SaW • operaTioN aNd parTS MaNual — reV. #0 (02/17/12) — page 33
transMissiOn EnGaGE lEvEr assy.
No. parT No. parT NaMe QTY. reMarKS
1 28825-351 LEVER ASSY. TRANS. ENGAGE 1
2 3360 GRIP, 1/4 X 1 BLACK 1
3 36720 MOUNT ASSY., LEVER RED 1
4 0655 SCREW, HHFS 5/16-18 X 3/4 GR5 4
5 10136 WASHER, FLAT SAE 3/8 6
6 6014 B PIN, COTTER 3/32D X 1.0 1
7 5291 PIN, CLEVIS 3/8 2
8 0300 B WASHER, FLAT SAE 5/16 2
9 49071 NUT, FLANGED SERRATED PLTD 5/16-18 8
10 08326-019 PIN, CLEVIS 3/8 X 2” USEABLE LENGHT 1
11 2199 NUT, HEX JAM 3/8-24 2
12 08327-012 YOKE END, 3/8-24 X 2.50 2
13 28830-001 ROD, TRANS. ENGINE 1
14 28819-351 TRANS. BRACKET ASSY. 1
