Sp2S20h paVeMeNT SaW • operaTioN aNd parTS MaNual — reV. #0 (02/17/12) — page 29
Manual raisE anD lOwEr assy. (20 in.)
No. parT No. parT NaMe QTY. reMarKS
1 28793-352 JACKPOST ASSY. 1
2 2621 ZERK, GREASE STR. 1/4-28 1
3 28806-001 JACKSCREW 1
4 28083-001 BEARING, FLANGE 1
5 28809-001 SPACER, JACKSCREW 1
6 4568 PIN, ROLL 3/16 X 1 1
7 28877-351 SCREW COVER ASSY., RED 1
8 49048 SCREW, HHFS 1/4-20 X 3/4 GR5 3
9 0948 WASHER, FLAT SAE 1/4 4
11 0424 SCREW, HHC 1/4-20 X 1 2
12 1162 A CAP,GREASE ZERK, #2 1
13 10024 NUT, NYLOC 1/4-20 2
14 1121 SCREW, HHC 3/8-16 X 2 3/4 1
15 1876 NUT, HEX JAM 3/8-16 CLASS 2B 1
16 4403 KNOB, SHIFT 1
17 28808-002 ARM-CRANK 1
