Sp2S20h paVeMeNT SaW • operaTioN aNd parTS MaNual — reV. #0 (02/17/12) — page 17
cOnsOlE assy.
No. parT No. parT NaMe QTY. reMarKS
1 28796-351 HANDLE ASSY. 1
2 15081 GRIP, 1” ID 2
3 38274 SCREW, HHC 3/8-16 X .75 4
4 1475 CONNECTOR SPLICE TAP 1
5 35127 SWITCH, KILL MAGURA 1
6 28091-401 SHIFT CONTROL ASSY. 1
7 35299 SCREW, PHP M4-0.7X25MM 2
8 28834-001 COVER, REAR 1
9 19266 NUT, BLIND 1/4-20X.27-165 8
12 49048 SCREW, HHFS 1/4-20 X 3/4 GRD 5 4
13 35155 HARNESS, FCG KILL SWITCH 1
14 28791-351 HOUSING ASSY. 1
15 28805-001 COVER, CONSOLE SIDE 1
16 29013-001 WRENCH, BOX END 1 1/2 1
