background image

HHXD5 RIDE-ON TROWEL • OPERATION MANUAL — REV. #3 (08/15/14) — PAGE 15

SPECIFICATIONS

NOTES:

1.

Sound Pressure and Power Levels are “A” weighted Measures per ISO 226:2003 (ANSI S1.4-1981). They are measured with the operating
condition of the machine which generates the most repeatable but highest values of the sound levels. Under normal circumstances, the sound
level will vary depending on the condition of the material being worked upon.

2.

The vibration level indicated is the vector sum of the RMS (Root Mean Square) Values of amplitudes on each axis, standardized to an 8 hour
exposure period, and obtained using operating condition of the machine that generates the most repeatable but highest values in accordance
with the applicable standards for the machine.

3.

Per EU Directive 2002/44/EC, the daily exposure action value for whole body vibration is 0.5 m/s

2

A(8). The daily exposure limit value is

1.15 m/s

2

A(8).

Table 2. Noise and Vibration Emissions

Guaranteed ISO 11201:2010 Based

Sound Pressure Level at Operator Station in dB(A)

98

Guaranteed ISO 3744:2010 Based

Sound Power Level in dB(A)

120

Whole Body Vibration Per ISO 2631-1:1997+A1:2010

in m/s

2

∑A(8)

0.06

Table 3. HHXD5 Engine Specifications

Model

Vanguard DM950DT

Type

Diesel, Turbo

Cylinders

3

Displacement

58.1 cu.in. (953 cc)

Power (Maximum Output)

31 HP (21.1 kW) @3600 rpm

Bore and Stroke

2.83 in. x 3.07 (72 mm x 78 mm)

Maximum Torque (Intermittent)

72.1 Nm @ 2400 rpm

Compression Ratio

24.8

Cooling System

water-cooled

Engine Oil Capacity

3.2 qt. (3 liters)

3.5 qt. (3.3 liters) w/ oil filter replacement

Lubricating System

Pressure feed with spin-on filter

Fuel Tank

9 gal. (34 liters)

Fuel Delivery System

Direct Injected

Helical Gearbox Gear Compound Capacity

144 oz. (4.26 liters)

ISO 22O AGMA GR 5EP

Fuel

Diesel - No. 2-D (ASTM D975) Cetane rating 40 or higher

Starting System

12V Electric Starter with Glow Plug

Dry Weight

196 lbs. (89 Kg)

Dimensions (L x W x H)

17.8 in. x 17.6 in. x 21.2 in

(452.6 mm x 447.6 mm x 538 mm).
