C-30HD — PARTS & OPERATION MANUAL — REV. #4 (03/06/01) — PAGE 63
C-30HD — HOPPER AND HOOD
C-30HD CONCRETE PUMP
HOPPER AND HOOD
NO. PART NO. PART NAME QTY. REMARKS
56 DURASEAT ................................................ 1 ............. SEE NOTE BELOW
57 EM18801 “O” RING 1
58 EM923348 5/8” LOCK WASHER .................................. 3 ............. REPLACES EM602
59 EM104 5/8-11X2 LG HEX BOLT 3
60 EM14140 HOOD 1
61 EM14141 HOPPER 1
62 EM14159 HOPPER SCREEN 1
63 EM14140-17 DOOR HINGE 1
64 EM14140-16 HOOD DOOR 1
65 EM14140-4 HOOD DOOR SUPPORT 2
66 EM14140-5 HOOD SUPPORT BRKT 2
67 EM406 1/2-13 HEX NUT 2
68 EM124 1/2-13X4 LG HEX BOLT 2
69 508659 LATCH 1
EM14164 KIT, DECAL SAFETY ................................. 1 ............. COMPONENTS NOT SHOWN
Note on item 56: A — Machines, built after July 1, 1990
use Duraseat P/N 14843 — This new seat is more
durable and can be used on older units.
