C-30HD — PARTS & OPERATION MANUAL — REV. #4 (03/06/01) — PAGE 57
C-30HD — OIL SYSTEM AND FUEL SYSTEM
C-30HD CONCRETE PUMP
OIL SYSTEM AND FUEL SYSTEM
NO. PART NO. PART NAME QTY. REMARKS
176 EM20426 MINI BARB ELBOW 2
177 EM20427 FUEL LINE A/R
178 FUEL TANK .......................................... 1 ........................... SEE NOTE
179 EM401 NUT, HEX 5/16-18 6
180 EM968354 WASHER, LOCK 5/16 ......................... 6 ........................... REPLACES EM601
181 EM923023 WASHER, FLAT 5/16 ........................... 10 ......................... REPLACES EM614
182 EM101 BOLT, HEX 5/16-18X1 1/2 4
183 FUEL TANK STRAP ............................. 2 ........................... SEE NOTE
184 EM20787 FUEL TANK CAP ................................. 1 ........................... SEE NOTE FOR PLASTIC FUEL TANK
185 EM20349 OIL PLUG 1
186 EM20412 MINI BARB FITTING 3
187 EM20415 CLEAR PLASTIC TUBE A/R
188 EM20417 NIPPLE 1
189 EM20418 TEE FITTING 1
190 EM911004 STREET ELBOW ................................. 1 ........................... REPLACES EM20416
191 EM20421 METERING VALVE 2
192 EM14401 ELECTRIC OIL PUMP 1
193 EM963030 BOLT, HEX 5/16-18X1 ......................... 2 ........................... REPLACES EM163
194 EM923027 WASHER, FLAT 3/8 ............................. 2 ........................... REPLACES EM611
195 EM14198 OIL RESERVOIR 1
196 EM1440 INSERT FITTING 1
Notes: Item #178 and 183 (A) — Machines prior to 1993
use P/N 14701 Fuel Tank (8 gal. capacity) and #14703
Fuel Tank Straps (two required). (B) — Machines after
1993 use P/N 14205 Fuel Tank (18 gal. capacity) and
#16185 Fuel Tank Straps (two required). (C) —
Machines after 2/1/95 use P/N 14205P Plastic Fuel
Tank (18 gal. capacity); P/N 2108 Gas Cap. Fuel tank
straps not required. Note: interchangeable with P/N
14205.
