PAGE 54 — C-30HD — PARTS & OPERATION MANUAL — REV. #4 (03/06/01)
C-30HD — COMPENSATING SPRING ASSEMBLY
EM14409
NOTE: If it is necessary to replace the spring, remove the piston
head assembly which allows the guide weldment to be
removed from the piston rod.
NOTE: Grease the compensator piston rod
daily at both fittings. Failure to grease
regularly may cause the piston rod to
“seize” in the guide tube resulting in
severe pulsations of material in the hose.
EM20412
EM20415
EM18409
EM14335
EM16179
EM16179
EM704
EM20812
EM16179
EM14334
EM14806
