WT5C/WTe5C WaTer Trailer • operaTion manual — rev. #1 (06/05/13) — page 15
Components (water trailer)
1. Water Tank — Capacity is 500 gallons (1,893 liters).
Fill with clean water with no debris.
2. Water Tank Fill Pipe — 2” diameter steel pipe. Connect
the 2" QD coupler end of this pipe to a fire hydrant.
An interface hose will be required to connect from the
pipe's QD coupler to the fire hydrant.
3. Water Tank Cap — Remove this cap (12-inch diameter
fill port) to fill water tank if using a fire hydrant type
method.
4. Document Box — Storage for documentation and
other information regarding the water trailer.
5. Tires — This water trailer uses ST205/75D 14" size
tires. Replace with only recommended type tires. Never
tow water trailer with bad or worn tires.
6. 1.5" Cam and groove male QD port — This port can
be used as either a suction or discharge port depending
on the placement of the manifold control handle.
7. manifold Control Handle — 3-position handle.
Allows 3 diffrent modes of operation, off, discharge
or suction.
8. garden Hose Drain valve — When draining of the
water tank is required open this valve to drain water.
9. 2.0" Cam and groove male QD port — This port
(right-side) can be used as either a suction or discharge
port depending on the placement of the manifold
control handle.
10. garden Hose valve — When other options of filling
of the water tank are unavailable, a garden hose can
be connected to this valve to fill the water tank. It is
recommended that a rigid walled garden hose or
suction type garden hose be used for this purpose.
In addition this valve can be used as a discharge port
depending on the position of the manifold control lever.
See Table 5.
11. Spray Bar Control Handle — 2-position handle, allows
spary bar to be turned either on or off.
12. Drain Plug — Remove this plug to drain water from
the pump.
13. Fill Cap — Prior to operation, the pump casing should
be filled with water. Remove this cap to add water to
the pump. After the initial prime, a sufficient amount of
water will be retained in the casing so that the operator
will not need to re-prime later.
14. Coupler Adapter — Attach either a 2-5/16" ball coupler
or 3-inch pintle eye ring coupler to this adapter.
15. Hydraulic Brake actuator — This actuator (Model
WT5C only) will be activated in the event of a
breakaway. The breakaway cable must be rigged to the
tow vehicle with appropriate slack that will activate the
system if the coupler connection comes loose.
16. electric Brake actuator — This actuator (Model
WTE5C only) will be activated in the event of a
breakaway. The breakaway cable must be rigged to the
tow vehicle with appropriate slack that will activate the
system if the coupler connection comes loose.
17. Engine — This water trailer uses a Honda
GX120UT2PX2, 3.5 HP air cooled 4-stroke, single
cylinder gasoline engine.
18. 2.0" Cam and groove male QD port — This port
(left-side) can be used as either a suction or discharge
port depending on the placement of the manifold
control handle.
19. Dust Cap — There are 3 dust caps that are used
with the manifold system. These caps prevent dirt
and debris from entering the water system when the
suction/discharge hoses are not connected.
20. Spray nozzles — Located at the rear of the water
trailer are two water spray nozzles. These nozzles can
operate under multiple pressure settings.
21. Storage Bin — Place hoses and accessories in this
bin during transport.
22. License Light — This light illuminates the license plate.
Whenever towing of the light tower is required, make
sure this light is operational.
23. Brake lights — Before towing the water trailer, make
sure that these lights are operational and are working
correctly. Never tow the water trailer if these lights are
inoperative.
