page 10 — WT5C/WTe5C WaTer Trailer • operaTion manual — rev. #1 (06/05/13)
speCifiCations (pump/trailer)
Table 1. Specifications
Water Tank
Type Low Profile
Style Rotomolded - Seamless with Baffles
Fill Port 12" - Vented Port
Material Polypropylene - 3/16" Wall - Repairable
Fill Rate 5 min. Full (Fill at Full Throttle)
Capacity 500 gallons (1,893 liters)
Weight w/ Empty Water Tank 1,428 lbs (648 kg)
Weight w/ Full Water Tank 5,850 lbs (2,654 kg)
Pump
Type 2" (51mm) Centrifugal
Maximum Flow 158 GPM (600 LPM)
Maximum Head 115 ft (35 meters)
Dry Net Weight 53 lbs (24 kg)
Trailer and Frame
Material Formed Steel Channe Frame
Number of Axles 2
Capacity - Axle Rating 3,500 lbs. (1,567 kg) ea.
Tires ST205/75D 14"
Certifications DOT
Brakes (Model WT5C) Surge Hydraulic-Actuated Drum Brakes
Brakes ( Model WTE5C) Electric-Actuated Drum Brakes
Hitch 2-5/16" ball or 3" pintle
Jack 2,000 lbs. (907 kg)
Hose Bin Formed Steel
Water operations
Delivery Methods
Pressurized 1.5" and 2" Left/2" Right
Two Std. Garden Hose Adapters:
Adapter #1 Pressurized (Upper)
Adapter #2 Drain Only (Lower)
Pressurized Rear Spray Nozzles
Fill Methods
Municipal Fire Hydrant - QD
1.5" and 2" QD Cam and Groove Adapter
Two Std. Garden Hose Adapters
