MVC82VE/VEW COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (02/05/09) — PAGE 51
ROBIN EX170D40103 ENGINE — CARBURETOR ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
210
2776230230
CARBURETOR ASSY .................................1 ................INCLUDES ITEMS W/ #
1# 2776253508
THROTTLE
VALVE
1
2# 2096235108
SCREW
1
3# 2776252508
CHOKE
VALVE
1
5#
2466242008
PILOT JET
1
8#
2776252008
CHOKE LEVER
1
11#
2776253118
THROTTLE SHAFT A
1
12# 2276245108
BOLT
1
14# 2776250008
NEEDLE
1
15# 2776251508
PIN
1
16#
2776250608
FLOAT BODY ASSY
1
17# 2146245008
PACKING
1
18#
2146254008
CHAMBER PACKING
1
19# 2266250608
FLOAT
1
20#
2776244008
MAIN NOZZLE
1
22#
2266241208
MAIN JET
1
24# 2266270118
CLIP
1
28# 2776236008
BOLT
1
40# 1066255608
SCREW
1
41# 2836235708
SPRING
1
44#
2486241008
AIR JET
1
45#
1066241008
AIR JET (PILOT)
1
62# 2366268008
SEAL
1
79# 2366254108
PACKING
1
102#
2466239008
SEAL
1
144#
2776255308
NUT
1
224
2774380101
CHOKE LEVER CP
1
300#
2796210310
COCK BODY A ............................................1 ................INCLUDES ITEMS W/ $
302#$ 2776211018
PACKING
1
303#$ 2776210018
CUP
1
325#
2776255208
O RING
1
327# 1656237708
SCREW
2
540
27732902J1
INSULATOR CP ..........................................1 ................INCLUDES ITEMS W/ &
550&
27735903J3
GASKET2 (INSULATOR)
1
560&
27735902J3
GASKET1 (INSULATOR)
1
