MVC82VE/VEW COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (02/05/09) — PAGE 45
ROBIN EX170D40103 ENGINE — GOVERNOR ASSY.
NO. PART NO. PART NAME QTY. REMARKS
10 2774230123 GOVERNOR LEVER 1
20 2774220133 GOVERNOR SHAFT 1
30 2774270111 GOVERNOR ROD CP 1
40 2774280123 ROD SPRING 1
50 0031305000 CLIP 1
60 0130060240 BOLT AND WASHER ASSY 1
70 0186060020 NUT 1
80 2794250263 GOVERNOR SPRING 1
310 2774330601 SPEED CONT.LEVER CP2 1
322 2774370101 LINK ROD CP 1
340 2774350203 STOP PLATE 1
350 2774450103 WASHER 1
355 0217060070 FRICTION WASHER 1
360 0043106250 SCREW 1
365 2374500423 SPRING (ADJUST) 1
395 2774390203 CLAMP 1
396 0131050030 SCREW AND WASHER ASSY 1
435 2774600201 SPEED CONT. BRACKET CP 1
440 0043104080 SCREW 1
450 0023506000 SELF LOCK NUT 1
480 2774510303 RETURN SPRING 1
485 0110060020 FLANGE BOLT 2
