MVC82VE/VEW COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (02/05/09) — PAGE 47
NO. PART NO. PART NAME QTY. REMARKS
10 2775120201 BLOWER HOUSING CP 1
20 0732005470 LABEL (TRADEMARK) 1
40 0110060030 FLANGE BOLT 4
60 2775271121 BAFFLE 1 (CASE) CP 1
61 2775270203 BAFFLE 2 (HEAD) 1
80 0010406160 FLANGE BOLT 1
81 0110060020 FLANGE BOLT 1
210 2695020130 RECOIL STARTER ASSY ...........................1 ................INCLUDES ITEMS W/ #
210-1# 2705011508 SPIRAL SPRING 1
210-2# 2695012008 REEL 1
210-3# 2825011118 STARTER ROPE 1
210-4# 2615010008 STARTER KNOB 1
210-5# 2705012508 RATCHET 2
210-6# 2275013108 FRICTION SPRING 1
210-7# 2275013508 RETURN SPRING 2
210-8# 2705026108 RATCHET GUIDE 1
210-11# 2695014518 STARTER PULLEY 1
210-49# 2275015208 SET SCREW 1
220 0110060010 FLANGE BOLT 4
ROBIN EX170D40103 ENGINE — COOLING, STARTING ASSY.
