MVC82VE/VEW COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (02/05/09) — PAGE 33
VIBRATOR ASSY
NO. PART NO. PART NAME QTY. REMARKS
61 418117730 VIBRATING CASE 1
62 001221445 BOLT 14X45 T 4
63 030214350 WASHER, LOCK M14 4
64 031114260 WASHER, FLAT M14 4
65 418456950 CASE COVER/PULLEY 1
66 060403020 OIL SEAL TC-30458 1
67 418456960 CASE COVER/SHUT OFF 1
68 418456970 PACKING 2
69-1 001220820 BOLT 8X20 T 8
69-2 030208200 WASHER, LOCK M8 8
70 418460130 COVER SEAL, VIBRATOR 1
71 418343630 ECC. ROTOR SHAFT 1
72 040406307 BEARING 6307C4 2
73 418456981 PULLEY/VIB. 1
74 951401920 KEY 7X7X30 1
75 952403450 WASHER 11X35X4.5 1
77-1 001221030 BOLT 10X30 T 1
77-2 030210250 WASHER, LOCK M10 1
78 953400270 PLUG 1/4X14 10L 1
79 953405260 PACKING 1/4 (CU) 1
