MVC82VE/VEW COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (02/05/09) — PAGE 39
ROBIN EX170D40103 ENGINE — CRANKSHAFT, PISTON ASSY.
NO. PART NO. PART NAME QTY. REMARKS
10 2772020141 CRANKSHAFT CP 1
50 0180140020 FLANGE NUT 1
70 0323030010 WOODRUFF KEY 1
80 0320050150 KEY 1
90 0200080140 WASHER 1
100 0110080250 FLANGE BOLT 1
310 2772250110 CONNECTING ROD ASSY, 84.5CDX25B 30D-16D ...1 ...........INCLUDES ITEM W/ #
310 2772250200 CONNECTING ROD ASSY, 0.25 U.S. .........................1 ...........INCLUDES ITEM W/ #
320# 2772300103 CONNECTING ROD BOLT 2
350 2772330113 PISTON PIN 1
360 27723401J3 PISTON, STD (67Dx40H) 1
360 27723403J3 PISTON, 0.25 O.S. (67Dx40H) 1
360 27723404J3 PISTON, 0.50 O.S. (67Dx40H) 1
370 2772351137 PISTON RING SET, STD(67D) 1
370 2772351217 PISTON RING SET, 0.25 O.S. 1
370 2772351317 PISTON RING SET, 0.50 O.S. 1
380 0565160010 CLIP 2
