PAGE 18 — MVC82VE/VEW COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (02/05/09)
OPERATION
INITIAL STARTUP
Place the fuel valve lever (Figure 10) in the "ON" 1.
position.
Fuel Valve Lever Figure 10.
Place the Engine ON/OFF switch (Figure 11) in the 2.
"ON" position.
Engine ON/Off Switch Figure 11.
Place the Choke Lever (Figure 12) in the "OPEN" 3.
position.
Choke Lever Figure 12.
CAUTION
DO NOT attempt to run the compactor
until the Safety and Initial Start-up sections
have been read and understood.
FUEL
LEVER
ENGINE
ON/OFF
SWITCH
ON
OFF
Nnnn
OPEN
CLOSED
CHOKE
LEVER
Place the throttle lever (Figure 13) halfway between 4.
fast and slow.
Throttle Lever Figure 13.
Grasp the starter grip (Figure 14) and slowly pull it out. 5.
The resistance becomes the hardest at a certain
position, corresponding the compression point. Rewind
the rope a little from that point and pull out sharply.
Starter Grip Figure 14.
If the engine has started, slowly return the choke lever 6.
(Figure 11) to the CLOSED position. If the engine has
not started repeat steps 1 through 5.
Before the compactor is put into operation run the 7.
engine for 3-5 minutes.
Check for abnormal engine noises or fuel leaks. 8.
NOTICE
The CLOSED position of the choke lever enriches the
fuel mixture for starting a COLD engine. The OPEN
position provides the correct fuel mixture for normal
operation after starting, and for restarting a warm
engine.
THROTTLE
LEVER
FAST
SLOW
STARTER GRIP
CAUTION
DO NOT pull the starter rope all the way to the end.
DO NOT release the starter rope after pulling. Allow it
to rewind as soon as possible.
