MVC82VE/VEW COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (02/05/09) — PAGE 11
MVC82VE/VEW Specifi cations Table 1.
Centrifugal Force 3,080 lbf (13.7 kN)
Vibration Frequency 5600 vpm (93.3 Hz)
Traveling Speed 0 to 82 ft/min (0 to 25 m/min)
Plate Size (L x W) 22.4 x 17.7 in (570 x 450 mm)
Max. Area of Compaction 7,262 sq. ft./h (675 sq. meters/h)
Operating Weight (MVC82VE) 181 lbs. (82 kg)
Operating Weight (MVC82VEW) 198 lbs. (90 kg)
Vibrating Oil Capacity 0.15 quart (0.14 liter)
Water Tank Capacity (MVC82VEW) 11.6 quarts (11 liters)
Engine Specifi cations Table 2.
Model ROBIN EX170D40103
Type
Air-cooled, 4-stroke, slant single cylinder
horizontal shaft, gasoline engine
Valve Arrangement OHC
Bore X Stroke
2.64 in. X 1.89 in.
(67 mm x 48 mm.)
Displacement 10.3 cu. in. (169 cc)
Max Power Output 4.3 HP (4.2 KW) @ 4000 R.P.M.
Fuel Tank Capacity 3.8 quarts (3.6 liters)
Fuel Gasoline
Speed Control Method Centrifugal Flyweight Type
Lube Oil Capacity 0.63 quarts (0.6 liters)
Starting Method Recoil Start
SPECIFICATIONS
