PAGE 6 — VR-36HA • VIBRATORY ROLLER — PARTS & OPERATION MANUAL — REV. 6 (06/13/06)
Read and understand this manual before attempting to operate
the machine.
The VR-36H roller has been designed for asphalt application
and compaction of granular soils used in site preparation. Use
the machine only for the purpose intended and by experienced
personnel who understand this operating manual and all safety
decals.
Keep this manual with the machine and refer to it frequently.
DANGER! Indicates extreme care should be
taken to prevent personal injury during
operation, inspection, maintenance and
service.
CAUTION! Indicates when special observation is needed during
operation and maintenance of this machine.
SAFETY RULES
■ Completely familiarize yourself with the operation and safety
of this machine BEFORE USE.
■ DO NOT remove or modify any parts of the machine. Doing
so may result in the warranty becoming invalid.
■ DO NOT use the machine for any purpose other than that
which it is intended.
■ Always wear proper safety equipment:
hard hat
safety glasses
work clothes
safety shoes
protective gloves
respirator in dusty environments
DANGER! Stay Clear of turning points of
machine. This is a pinch point. Never place
yourself or allow anyone else to stand near the
unit while the engine is running.
■ Start the unit only when seated in the operator’s position.
(see starting instructions)
■ Whenever possible, always stop the unit on a stable, level
and hard surface. If the machine must be stopped on an
incline; before leaving the operator’s seat, secure the
parking brake and stop the engine; then chock both the
front and rear drums securely. Always remove the
ignition key to prevent unauthorized personnel from
operating the machine.
DANGER! Exhaust gasses are extremely
dangerous and cause death. Operate the
machine only in well ventilated areas.
■ If malfunction occurs in the travel lever mechanism, speed
and direction will be impossible to control. Immediately stop
the
■ In the event of hydraulic hose or pipe failure, promptly return
the travel lever to the “neutral” position, stop the engine
and set the parking brake.
■ If the steering system operates improperly, immediately stop
the engine and apply the parking brake.
■ When malfunctions occur, always remove the ignition key
and place a “DO NOT OPERATE” sign in the operator’s
seat.
INSPECTION PRIOR TO STARTING
DANGER! Perform inspections only with the
machine parked on a stable, level and hard
surface. Never inspect the unit with the engine
running. Inspections should only be performed
by trained and qualified personnel.
CAUTION! Perform the following checks before each operation
of the machine and only with the engine STOPPED!
■ Check hydraulic oil, engine oil, and fuel levels and for
leakage.
■ Check all hydraulic components and fittings for wear.
■ Insure smooth movement of the travel lever, throttle and
parking brake.
■ Check all fasteners (bolts & nuts) for tightness.
RULES FOR SAFETY OPERATION
