3.3: Connecting to Your Plumbing
Included with your MP880sB/MP880el Drinking water system is one installation kit, which includes all of the fixtures and
accessories needed to install your system below the sink. If you determine that your particular plumbing configuration
requires fixtures different from those included with your shipment, please contact Multipure’s Customer service office at
800.622.9206, ext. 175.
Determine Your Adapta Valve Configuration
If your residence has a cold water supply line with a 3/8” or 1/2" slip joint connection, you may use the Adapta Valve includ-
ed with your system to connect your Dws to the plumbing. The Adapta Valve assembly (MC922AsBl) includes both the
valve and threading adapter.
NOTE: When attaching the Adapta Valve to straight pipe
threads, use Teflon tape on the threads. Wrap the tape around
the pipe only once.
Adapta Valve
Threading adapter
13
(#14)
Reading the LED Display Plate
1. when you turn on the faucet, or when the button on the FMu is pressed, the leD on the leD
Display Plate blinks five (5) times to indicate the filter capacity status. The color of the leD indicates
the filter status:
a. Green = 30% - 100% filter capacity
b. Orange = 0% - 30% filter capacity
c. red = 0% filter capacity (the FMu will also play a long audible sound to indicate 0% capacity)
2. Multipure recommends ordering a new replacement filter (either online at
http://www.multipure.com/store/page6.html or by telephone at 800.622.9206) when the monitor
indicates 30% capacity or less.
3. The FMu will memorize the last remaining capacity in the event that the batteries lose power. It will restore the last
remaining capacity when new batteries are installed.
nOTe: As with all drinking water treatment devices which reduce certain contaminants by mechanical filtration, the capacity
of the filter can vary, and is dependent upon the type and level of contaminants in your water. If the system is used on water
with high levels of particulate matter, Multipure recommends the installation and use of an additional pre-filter element.
3.2-c: Installing the Capacity Monitor Faucet (continued)
1/2” slip joint nut
riser
3/8” or 1/2”
slip joint nut
angle stop valve
water supply line
before installation
water supply line with
Adapta Valve in 3/8” configuration
water supply line with
Adapta Valve in 1/2” configuration
A. B.
riser
Adapta Valve
1/2” configuration
1/2” slip joint nut
angle stop valve
angle stop valve
riser
1/2” slip joint nut
3/8” slip joint nut
Adapta Valve
3/8” configuration
