10
NOTE: The blue plastic tubing is attached to the faucet.
1. From the sink / countertop:
a. Place the larger soft black rubber washer over the faucet hole.
b. Place the cover plate on top of the large washer.
c. Place the smaller soft black rubber washer on top of the cover plate.
d. Place the faucet base over the smaller soft black rubber washer and atop the cover plate.
2. From under the sink:
a. slide the hard plastic black washer (with the smaller side up) upward over the blue tubing.
b. slide the lock washer upward, below the hard plastic washer.
c. slide the wing nut upward, below the lock washer.
d. Hand-tighten the wing nut to secure the faucet.
3.2-b: Installing the Standard Faucet
small black washer
large black washer
Cover Plate
Lock Washer
Blue Tubing
Plastic Washer
Wing Nut
COUNTERTOP
Complete Faucet Assembly
with Blue Tubing
MC652
