MTS Series 256 Servovalve User Manual
Page 22
Series 256 Servovalve Product Information
22
Specifications
Introduction
Series 256.18D Flow vs. Frequency Performance Curves
Series 256 Servovalve - Rise Time
1000
100
10
1
1
10
100
1000
3.8
38
380
3800
Flo
w in Lit
ers P
er Minut
e
Frequency in Hz
256.18D
-05
-01
-02
Flo
w
in Gall
on
s Per Min
u
te
Main Stage
Spool Stroke
90%
Opening
10%
Opening
Time
tr
tr
