Replacing the fuse, Replacing the fuse 60 – MTS Series LX Laser Extensometer User Manual
Page 60
LX Laser Extensometer
Replacing the Fuse
Maintenance
60
Replacing the Fuse
Turn the power switch off and disconnect the line cord from the AC power
line.
Be sure power is disconnected before attempting to replace any fuses.
1. The fuse holder is in the power entry module which is located on the rear
panel. The AC line cord MUST be removed from the power entry module in
order to open fuse compartment.
2. Insert small screw driver blade into slot above POWER SWITCH and
carefully pry open fuse compartment cover and pull out fuse drawer.
3. Remove fuse from fuse drawer, inspect, and replace fuse if necessary with a
new one of the same type and rating.
Replace fuses only with the specified type and rating.
Using incorrect fuses present a safety hazard and damage the instrument.
4. Reinstall the fuse drawer and close the fuse compartment cover.
CAUTION
CAUTION
