Component Identification
Series 298 Hydraulic Service Manifold
Introduction
15
Component Identification
Refer to the following table for information on the components shown below.
Servovalve
Servovalve
Mounting
Cover Plate
Pressure
Accumulator
Return
Accumulator
Inlet
Filter
Shut-Off Valve
Proportional
Valve
(298.12 only)
Differential
Pressure
Switch
Hydraulic
Input
Port
Hydraulic
Return
Port
On/Off
Valve
(298.11 only)
Hydraulic
Ports for
Lifts, Locks,
and Grips (behind
filter manifold)
