Model 505G2.07/.11 SilentFlo™ HPU
14
Product Information CD
Product Information CD
A Product Information CD is supplied with the HPU (MTS part number
100-227-354). The Product Information CD includes the electrical and hydraulic
schematics along with the configuration drawings. The Product Information CD
also contains the product specifications and other reference documents to aid
MTS qualified service personnel. These documents include:
Drawing Number
Description
700005313
Product Specifications
100025526
Series 505 SilentFlo™ HPU Lift and Move Instructions
700005263
505.07 Configuration Drawing
700000263
505.07 Hydraulic schematic
700004937
505.07 small PLC Electrical Schematic (200 - 480 VAC)
700005213
505.07 large PLC Electrical Schematic (200 - 480 VAC)
700004942
505.07 small PLC Electrical Schematic (575 VAC)
700005293
505.07 large PLC Electrical Schematic (575 VAC)
700005263
505.11 Configuration Drawing
700000264
505.11 Hydraulic schematic
700004965
505.11 small PLC Electrical Schematic (200 - 480 VAC)
700005214
505.11 large PLC Electrical Schematic (200 - 480 VAC)
700004966
505.11 small PLC Electrical Schematic (575 VAC)
700005294
505.11 large PLC Electrical Schematic (575 VAC)
050000536
Hydraulic Fluid Care Guide
015164000
Heat Exchanger Care Guide
