Series 642 bend fixture specifications – MTS Series 642 Bend Fixtures User Manual
Page 17
Series 642 Bend Fixtures Product Information
Introduction
17
Series 642 Bend Fixture Specifications
Dynamic Force
Weight
Dynamic Force
Model Number
Dynamic Force
*
*. Static and dynamic force rating depends upon
the roller diameter.
642.001
.09 kN (200 lbf)
642.01
10 kN (2.2 kip)
642.10
100 kN (22 kip)
642.25
250 kN (55 kip)
Weight
Model Number
Weight
kg
lb
642.001
0.7
1.5
642.01A
5
10
642.10B
22
48
642.25
60
130
