Advantage™ Pneumatic Grips
Selecting Face Surfaces
Operation 46
Round wedges
Vee-shaped wedges The vee wedge specimen diameter specification represents the diameter range if
the specimen is installed from the side of the grips (the widest opening). The
specimen diameter also lists the maximum specimen diameter if the specimen is
installed from the top of the grips.
Surface Specimen Diameter Part Number
Surfalloy 10 mm 50507912
Surfalloy 15 mm 50507913
Surfalloy 25 mm 50507914
Surfalloy 0.5 in 50507915
Surfalloy 1 in 50507916
Surface
Specimen Diameter
*
* The specification has a diameter range for installing the specimen from the side of
the grips. The second specification is the maximum diameter if the specimen is
installed from the top of the grips.
Part Number
Serrated 3.0–8.1/9.4 mm (0.12–0.32/0.37 in) 50507908
Serrated 8.9–10.9/15.2 mm (0.35–0.43/0.60 in) 50507909
Serrated 14.0–18.0/20.8 mm (0.55–0.71/0.82 in) 50507910
Serrated 20.1–22.9/27.2 mm (0.79–0.90/1.07 in) 50507911
