MTS Advantage Pneumatic Grips - Manual (Page 45)

Selecting Face Surfaces
Advantage™ Pneumatic Grips Operation 45
Grip Faces for the 10,000 N Grips
These grip faces are wedges for the high tensile grips rated at 10,000 N (2000
lbf). The usable width of these wedges is 25 mm (1 in) or 50 mm (2 in), the
insertion depth is 38 mm (1.5 in), and the temperature range is -40°C to 177°C (-
40°F to 350°F). They are sold in matched sets of four.
Flat 25 mm (1 in)
wedges
Flat 50 mm (2 in)
wedges
Surface Specimen Thickness Part Number
90° Diamond 0–7.1 mm (0–0.28 in) 50507906
90° Diamond 7.1–14.4 mm (0.28–0.57 in) 50507907
Surfalloy 0–7.1 mm (0–0.28 in) 50507917
Surfalloy 7.2–14.4 mm (0.28–0.57 in) 50507918
Serrated 0–7.1 mm (0–0.28 in) 50507919
Serrated 7.1–14.4 mm (0.28–0.57 in) 50507920
Smooth 0–7.1 mm (0–0.28 in) 50507924
Smooth 7.1–14.4 mm (0.28–0.57 in) 50507925
Corrugated 0–7.1 mm (0–0.28 in) 50507929
Corrugated 7.1–14.4 mm (0.28–0.57 in) 50507930
Surface Specimen Thickness Part Number
90° Diamond 0–7.1 mm (0–0.28 in) 54585001
90° Diamond 7.1–14.4 mm (0.28–0.57 in) 54585002
Surfalloy 0–7.1 mm (0–0.28 in) 54585005
Surfalloy 7.2–14.4 mm (0.28–0.57 in) 54585006
Serrated 0–7.1 mm (0–0.28 in) 54507909
Serrated 7.1–14.4 mm (0.28–0.57 in) 54507910
Smooth 0–7.1 mm (0–0.28 in) 54507913
Smooth 7.1–14.4 mm (0.28–0.57 in) 54507914
Corrugated 0–7.1 mm (0–0.28 in) 54507917
Corrugated 7.1–14.4 mm (0.28–0.57 in) 54507918
