Page 30
Advantage™ Pneumatic Grips
Installation Using the Mounting Pin
Installation
30
Installation Using the Mounting Pin
This section describes how to install of the Advantage Pneumatic Grips using the
standard mounting pin.
Installation Components Using the Mounting Pin
Servohydraulic
adapter
If you are installing the grips on a
servohydraulic load unit and want to use the
standard mounting pins, you must install a
load unit mounting adapter on the actuator
and on the force transducer.
Mounting Dowel
Mounting Pin
Locking Collar
Grip Assembly
Load Unit Mounting Adapter
10 N
200 N/2000 N
10,000 N
