MK-101 Pro24 CONTENTS
CONTENTS
MK-101 Frame
and Water Basin
MK-101
Cutting Head
Diamond Blade Adjustable
Cutting Guide
Electric Water
Pump
45° Miter
Cooling Transfer
Tube
Flow Adjusting
Clamp
Drain Plug
Blade Wrench
Splash Guard
Owners Manual Pump Manual Pump Manual Stand w/ Casters
Dressing Stone Side Table
Dual Flat 45°
Angle Guide
Protractor
03.2013
MK-101 Pro24
MK-101 Pro24 Tile Saw OWNER’S MANUAL & OPERATING INSTRUCTIONS
www.mkdiamond.com
Caution: Read all safety and operating instructions before using this equipment. This owners manual MUST accompany the equipment at all times.
Revision 300 Manual Part No. 158808
In your container, you will find one (1) MK-101 frame and water basin, one (1) MK-101 Cutting Head, one
(1) 10-inch wet cutting continuous rim diamond blade, one (1) adjustable cutting guide, one (1) electric
water pump, one (1) protractor, one (1) dual flat 45 ° angle guide, one (1) 45 ° miter, one (1) blade wrench,
one (1) splash guard, one (1) cooling transfer tube, one (1) flow adjusting clamp, one (1) drain plug, one
(1) dressing stone, one (1) side table, one (1) owners manual, one (1) pump manual, one (1) warranty
card and one (1) stand.
UNPACKING
Your MK-101 has been shipped from the factory thoroughly inspected. Only minimal assembly is
required.
CAUTION Use proper lifting techniques when lifting the MK-101 Pro24.
