Page 23
PVS-23
VERTICAL SEAM
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
Double Bead Tape Sealant
Fastener (by others)
Tube Sealant
Counter Flashing
Rakewall
3:12 SLOPE
MINIMUM
#12-14 x 1
1
/
4
" Shoulder SD (12" o.c.)
#12-14 x 1
1
/
4
" SD XL (12" o.c.)
1
/
8
x
3
/
16
" Pop Rivet (12" o.c.)
Rake Cleat
Floating Rake Angle
Vertical Seam Panel
3:12 SLOPE
MINIMUM
Double Bead Tape Sealant
Fastener (by others)
Tube Sealant
Counter Flashing
Rakewall
#12-14 x 1
1
/
4
" Shoulder SD (12"o.c.)
#12-14 x 1
1
/
4
" SD XL (12"o.c.)
1
/
8
x
3
/
16
" Pop Rivet (12"o.c.)
Rake Cleat
Floating Rake Angle
Field bend panel rib up 1
3
/
4
"
verTiCal seam
r
ake
P
araPeT
(o
ff
m
odUle
) d
eTail
r
ake
P
araPeT
(o
n
m
odUle
) d
eTail
Vertical Seam Panel
