Page 19

PVS-19
VERTICAL SEAM
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
Extended Eave
Double Bead Tape Sealant
Cleat
Tube Sealant
Vertical Seam Panel
#10-16 x 1" PHD (12" o.c.)
3:12 SLOPE
MINIMUM
#12-14 x 1
1
/
4
" Self Driller XL (see below)
CAUTION
Additional screws
may be required for
high snow loading
and steep slopes.
Universal Gutter/ D.S. Strap (3'-0" o.c.)
Double Bead Tape Sealant
Box Gutter
Vertical Seam Panel
1
/
8
" x
3
/
16
" Pop Rivet (every strap)
3:12 SLOPE
MINIMUM
CAUTION
In locations where heavy
rainfall or severe ice and
snow may occur, Metal
Sales' standard gutters may
not be suitable for use.
Tube Sealant
#12-14 x 1-
1
/
4
" Self Driller XL (see below)
e
xTended
e
ave
d
eTail
verTiCal seam
b
ox
g
UTTer
d
eTail
3
1
2
4
Vertical Seam Fastening Pattern
3
1
2
4
Vertical Seam Fastening Pattern
