INSTALLATION INSTRUCTIONS
Exhaust hose installation:
The exhaust hose and adaptor must be installed or removed
in accordance with the usage mode.
COOL mode
FAN or DEHUMIDIFY mode
Install
Remove
The duct can be compressed or extended moderately
according to the installation requirement, but it is
desirable to keep the duct length to a minimum.
1. Install the window Exhaust adaptor (flat mouth) onto the
exhaust hose as shown in Fig.18. Refer to the previous
pages for window kit installation.
IMPORTANT:
DO NOT OVER BEND THE DUCT (SEE Fig.21)
NOTE:
Fig.18
Fig.19
Fig.20
Fig.21
Flat mouth
Pu
sh
in
Hook
2. Place the Exhaust hose over against the air outlet opening
hook(See Fig.19) and flat the other end(See Fig.20) for
quick installation.
14
