Control technology | IPC Backup & Restore
User interface
Control & function elements
3.1.1 Title bar
In the Title bar in the upper position of the application window, the Program icon and
Program name are displayed in the left-most position and the Window icons are displayed
in the right-most position:
 The view of the application window can be changed via the Window icons 0 1 2 . Here,
the following is distinguished:
– Icon in the Task bar ()
– Window size ()
 When clicking the Program icon you open the System menu which also contains
commands for positioning and changing the size of the application window.
 Click the Window icon U or double-click the Program icon to exit »IPC Backup &
Restore«.
3.1.2 Menu bar
Via the Menu bar you can access all menu commands.
 By clicking a main menu item you open the corresponding menu, and the menu items
contained therein are displayed.
 By clicking a menu item you execute the function associated.
– Menu items displayed in light grey are deactivated in the current program status.
3.1.3 View bar
CF card USB stick Device replacement

Note!
The Operating range changes depending on the view selected.
