9400 Technology applications | Actuator – torque
Parameter setting & configuration
Parameterisable function blocks
C03512/1...15
0.000
s
1000.000 Acceleration time 1...15
• Initialisation: 0.000 s
C03513/1...15
0.000
s
1000.000 Deceleration time 1...15
• Initialisation: 0.000 s
C03514/1...15
0.000
s
1000.000 S-ramp time 1...15
• Initialisation: 0.000 s
C03515
0
15 Active ramp parameters
• Read only
C03520
Profile mode
• Read only
0 Profile generation with linear ramps
• Referred to the reference speed
(C00011).
1 Profile generation with jerk
limitation (S-shaped ramps)
10 Profile generation with linear ramps
• Referred to the reference speed
(C00011).
• At an edge change at the input
bStop referred to the current
setpoint (constant time).
• The setpoint applied at the input
dnExtSpeedSetpoint_n is used as
the start value.
C03521
-200.00
%
200.00 Setpoint at the input
• Read only
C03522
-200.00
%
200.00 Target setpoint
• Read only
C03523
-200.00
%
200.00 Setpoint at the output
• Read only
C03524
Status "Target setpoint reached"
• Read only
0 Target setpoint not yet reached
1 Target setpoint reached
C03525
0.000
rpm
50000.000 Load reference speed
• Read only
C03526
0.000
rpm
50000.000 Load setpoint speed
• Read only
C03527
0.0000
Unit/t
214000.0000 Reference speed
• Read only
C03528
-214000.0000
Unit/t
214000.0000 Setpoint speed
• Read only
C03529
Character string from AxisData
Speed unit
• Read only
C03537
-200.00
%
200.00 External setpoint
• Display of input signal
dnExtSpeedSetpoint_n.
C03538
-200.00
%
200.00 Current motor speed
• Display of input signal
dnActualMotorSpeed_n.
C03539/1
Invert setpoint
• Display of input signal
bInvertSetpoint.
0 Setpoint not inverted
1 Setpoint inverted
Parameter
Possible settings
Information
