9400 Technology applications | Actuator – torque
Parameter setting & configuration
Parameterisable function blocks
30
L
EDS94TA10020xxxx EN 1.1 - 10/2008
4.13 Parameterisable function blocks
This subchapter lists all relevant parameterisable function blocks of the technology
application and the corresponding parameters in alphabetical order.
4.13.1 L_DevApplErr1
4.13.2 SpeedRamp
Is an instance of Function
L_DevApplErr Error handling
Application error messages (C 29)
Parameter Possible settings Information
C03900 980 999 Module ID
C03901/1...8 0 65535 Error ID
C03902/1...8 Error response
0 None
1 Fault
2 Trouble
3 Quick stop by trouble
4 Warning locked
5 Warning
6 Information
Is an instance of Function
L_SdSpeedSet Ramp generator for speed limit value
Speed limit value conditioning (C 16)
Parameter Possible settings Information
C03500/1...15 -200.00 % 200.00 Fixed setpoint 1...15
C03501 0 15 Active setpoint
• Read only
C03502 0.000 s 1000.000 Basic acceleration time
• Initialisation: 1.000 s
C03503 0.000 s 1000.000 Basic deceleration time
• Initialisation: 1.000 s
C03504 0.000 s 10.000 Basic S-ramp time
• Initialisation: 0.100 s
C03507 Polarity of bStop input
0 Active HIGH
1 Active LOW
C03508 0.00 % 100.00 Setpoint tolerance reached
• Initialisation: 1.00 %
