Parameter setting
6-42
L
BA2141 EN 1.0
Signal configuration (L-C0005) AIF-OUT.W1 AIF-OUT.W2 AIF-OUT.W3 AIF-OUT.D1
Speed control 1003/1013/1113
MCTRL-NACT
Actual speed
100 % = 16383
MCTRL-MSET2
Torque display
100 % = 16383
MCTRL-NSET2
Speed controller input
100 % = 16383
Torque control 4003/4013/4113
MCTRL-MSET2
Torque display
100 % = 16383
MCTRL-NACT
Act. speed in %
100 % = 16383
MCTRL-NSET2
Speed controller input
100 % = 16383
DF master 5003/5013/5113
MCTRL-NACT
Actual speed
100 % = 16383
MCTRL-MSET2
Torque display
100 % = 16383
MCTRL-NSET2
Speed controller input
100 % = 16383
DF-slave bus 6003/6013/6113
MCTRL-NACT
Actual speed
100 % = 16383
MCTRL-PHI-ACT
Actual phase
MCTRL-MSET2
Torque setpoint in %
100 % = 16383
DF-slave cascade 7003/7013/7113
MCTRL-NACT
Actual speed
100 % = 16383
MCTRL-PHI-ACT
Actual phase
MCTRL-MSET2
Torque setpoint in %
100 % = 16383
not assigned
Cam profiler 1xxx3
MCTRL-NACT
Actual speed
100 % = 16383
not assigned not assigned
Positioning 2xxx3
MCTRL-NACT
Actual speed
100 % = 16383
not assigned not assigned
vector control
1xx3/4xx3/5xx3/
10xx3
MCTRL-NACT
Actual speed
100 % = 16383
MCTRL-IACT
MCTRL-NSET2
Speed controller input
100 % = 16383
vector control
6xx3/7xx3/8xx3/
9xx3
MCTRL-NACT
Actual speed
100 % = 16383
MCTRL-PHI-ANA
MCTRL-MSET2
Torque setpoint in %
100 % = 16383
vector control 110x3 not assigned not assigned not assigned
For more detailed information about the function block AIF-OUT see the Manual 93XX.
