Parameter setting
6-33
L
BA2141 EN 1.0
6.5.2.1 Status word for 82XX
Bit 820X 821x,822x
00 Actual parameter set
0 = Parameter set 1 or 3 active
1 = Parameter set 2 or 4 active
Actual parameter set
0 = Parameter set 1 or 3 active
1 = Parameter set 2 or 4 active
01 IMP (pulse inhibit)
0 = Pulses for power stage enabled
1 = Pulses for power stage inhibited
IMP (pulse inhibit)
0 = Pulses for power stage enabled
1 = Pulses for power stage inhibited
02 I
max
(current limit reached)
0 = Current limit not reached
1 = current limit reached
I
max
(current limit reached)
0 = Current limit not reached
1 = current limit reached
03 not assigned f
d
= f
dset
0 = f
d
≠ f
dset
1 = f
d
= f
dset
04 f
d
= f
dset
0: f
d
≠ f
dset
1: f
d
= f
dset
RFG on = RFG off
0 = RFG on ≠ RFG off
1 = RFG on = RFG out
05 Qmin (f
d
≤ f
dQmin
)
0 = Qmin not active
1 = Qmin active
Qmin (f
d
≤ f
dQmin
)
0 = Qmin not active
1 = Qmin active
06 f
d
= 0 (act. frequency = 0)
0: f
d
≠ 0
1: f
d
> 0
f
d
> 0 (actual frequency value = 0)
0 = f
d
≠ 0
1 = f
d
> 0
07 Ctrl. inhibit (controller inhibit)
0 = controller not inhibited
1 = controller inhibited
Ctrl. inhibit (controller inhibit)
0 = controller not inhibited
1 = controller inhibited
08...11 Controller status
0 = Controller initialization
8 = Error active
Controller status
0 = Controller initialization
1 = Switch on inhibit
3 = Operation inhibited
4 = Flying-restart circuit active
5 = DC brake active
6 = Operation enabled
7 = Message active
8 = Error active
12 Overtemperature warning
0 = No warning
1 = Warning
Overtemperature warning
0 = No warning
1 = Warning
13 U
Gmax
(DC-bus overvoltage)
0 = No overvoltage
1 = overvoltage
U
Gmax
(DC-bus overvoltage)
0 = No overvoltage
1 = overvoltage
14 Direction of rotation
0 = CW rotation
1 = CCW rotation
Direction of rotation
0 = CW rotation
1 = CCW rotation
15 Ready
0 = not ready for operation
1 = ready for operation
Ready
0 = not ready for operation
1 = ready for operation
