Parameter setting
6-39
L
BA2141 EN 1.0
6.5.3.2 Control word for 8200 vector
Bit 8200vector Bit
Default setting:
C0001=3 if C0007 < 52
Default setting:
C0001=3 if C0007 > 51
00,
00 = C0046 active
01 = NSET1-JOG1 (C0037) active
00,
01 01 NSET1 JOG1 (C0037) active
10 = NSET1-JOG2 (C0038) active
11 = NSET1-JOG3 (C0039) active
Freely configurable by user
02 DCTRL1-CW/CCW
0 = not active
1 = active
y g y
03 AIF-CTRL-QSP
0 = not active
1 = active
04 NSET1-RFG1-STOP
0 = not active
1 = active
05 NSET1-RFG1-0
0 = not active
1 = active
06 MPOT1-UP
0 = not active
1 = active Freely configurable by user
07 MPOT1-DOWN
0 = not active
1 = active
08 Freely configurable by user
09 AIF-CTRL-CINH
0 = not active
1 = active
10 AIF-CTRL-TRIP-SET
0 = not active
1 = active
11 AIF-CTRL-TRIP-RESET
0 -> 1 = Edge from 0 to 1
12 DCTRL1-PAR2/4
0 = not active
1 = active
13 DCTRL1-PAR3/4
0 = not active
1 = active
Freely configurable by user
14 MCTRL1-DCB
0 = not active
1 = active
15 Freely configurable by user
