Parameter setting
6-30
L
BA2141 EN 1.0
6.5 Device control AIF-CTRL
6.5.1 General information
6.5.1.1 Output variable
network output SNVT_count nvoAIFStatus;
network output SNVT_count nvoAIFOut1;
network output SNVT_count nvoAIFOut2;
network output SNVT_count nvoAIFOut3;
The output network variable nvoAIFStatus is directly taken from the AIF status word.
The output network variables nvoAIFOut1 to nvoAIFOut3 are directly taken from the
corresponding AIF data words.
Output range
The possible bandwidth for the output variable is between 0 and 65535.
Update range
The variables are sent if the value changes or if the time set under Configuration Property Maximum
Send Time ( nciSndHrtBt ) has expired.
The variable value will not be sent quicker than set in Configuration Property Minimum Send Time
( nciMinOutTm ).
Standard Service Type
The Standard Service Type is acknowledged.
