Technical data
Interference voltage category according to EN 61800−3 and motor cable length
l
31
EDK82ZN903 DE/EN/FR 5.1
4.3
Interference voltage category according to EN 61800−3 and motor cable length
The limit values of the conducted noise emissions according to EN 61800 −3 (categories C2
or C1) are complied with if the following conditions are met:
ƒ
Specified permissible motor cable length is not exceeded.
ƒ
Low−capacitance motor cables are used.
ƒ
Filters E82ZZ... or E82ZN... are installed.
Operation with rated power (normal operation)
8200 vector
Interference voltage category according to EN 61800−3 and motor cable length
Component
Componente
Type
C2
max. [m]
C1
max. [m]
E82EV153K4B2xx
E82ZN22334B230
50
10
5)
E82ZN22334B230
10
0
5)
E82ZZ15334B230
50
10
5)
E82ZZ15334B230
10
0
5)
E82EV223K4B2xx
E82ZN22334B230
50
10
5)
E82ZN22334B230
10
0
5)
E82EV303K4B2xx
E82ZN30334B230
50
10
5)
E82ZN30334B230
10
0
5)
E82EV453K4B2xx
E82ZN45334B230
50
10
5)
E82ZN45334B230
10
0
5)
E82EV553K4B2xx
E82ZN55334B230
50
10
5)
E82ZN55334B230
10
0
5)
E82EV753K4B2xx
E82ZN75334B230
50
10
5)
E82ZN75334B230
10
0
5)
E82EV903K4B2xx
E82ZN90334B230
50
10
5)
E82ZN90334B230
10
0
5)
5)
at switching frequency f
ch
= 16 kHz; the interference voltage category C1 cannot be achieved
9300 vector
Interference voltage category according to EN 61800−3 and motor cable length
Component
Componente
Type
C2
max. [m]
C1
max. [m]
EVF9327−EV
E82ZN22334B230
50
10
5)
E82ZN22334B230
10
0
5)
E82ZZ15334B230
50
10
5)
E82ZZ15334B230
10
0
5)
EVF9328−EV
E82ZN22334B230
50
10
5)
E82ZN22334B230
10
0
5)
EVF9329−EV
E82ZN30334B230
50
10
5)
E82ZN30334B230
10
0
5)
EVF9330−EV
E82ZN45334B230
50
10
5)
E82ZN45334B230
10
0
5)
EVF9331−EV
E82ZN55334B230
50
10
5)
E82ZN55334B230
10
0
5)
EVF9332−EV
E82ZN75334B230
50
10
5)
E82ZN75334B230
10
0
5)
EVF9333−EV
E82ZN90334B230
25
10
5)
E82ZN90334B230
10
0
5)
5)
at switching frequency f
ch
= 16 kHz; the interference voltage category C1 cannot be achieved
