Technical data
Rated data
l
30
EDK82ZN903 DE/EN/FR 5.1
Mounting conditions
Mounting location
In the control cabinet
Mounting position
between mounting plate and basic device
Mounting position
Vertical, connections on top
Free spaces
at the top
> 150 mm
at the bottom
> 100 mm
to the sides
> 50 mm
4.2
Rated data
Basis of the data
Mains
Voltage
Voltage range
Frequency range
U
LN
[V]
U
LN
[V]
f [Hz]
3/PE AC
400
320 − 0 % ... 440 + 0 %
45 ... 65
3/PE AC
480
432 − 0 % ... 528 + 0 %
45 ... 65
3/PE AC
500
450 − 0 % ... 550 + 0 %
45 ... 65
Voltage
Frequency
Current [A]
Number of
phases
[V]
[Hz]
max. +45 °C
max. +55 °C
E82ZZ15334B...
400/480/500
50/60
43/43/43
26.8/26.8/26.8
3
E82ZN22334B...
400/480/500
50/60
42/42/42
26.3/26.3/26.3
3
E82ZN30334B...
400/480/500
50/60
55/55/55
34.3/34.3/34.3
3
E82ZN45334B...
400/480/500
50/60
80/80/80
50.0/50.0/50.0
3
E82ZN55334B...
400/480/500
50/60
100/100/100
62.5/62.5/62.5
3
E82ZN75334B...
400/480/500
50/60
135/135/135
84.3/84.3/84.3
3
E82ZN90334B...
400/480/500
50/60
165/165/165
103/103/103
3
Temperature in the control cabinet
Power loss
Inductance
Voltage drop
P
loss
[W]
L [mH]
DU [V]
E82ZZ15334B...
50
−
−
E82ZN22334B...
100
0.70
9
E82ZN30334B...
200
0.47
10
E82ZN45334B...
200
0.35
10
E82ZN55334B...
400
0.30
10
E82ZN75334B...
200
0.15
7
E82ZN90334B...
350
0.15
9
