Electrical installation
Wiring
Mains choke/mains filter assignment
5
l
114 EDK82EV222 DE/EN/FR 13.0
Wiring
Mains choke/mains filter assignment
Operation at rated power on 230 V mains, 1/N/PE
8200 vector Mains choke Interference voltage category (EN 61800−3) and motor cable
length
Component Component
Type Var. Type C2 Max.
[m]
C1 Max.
[m]
E82xV251K2C 0xx ELN1−0900H005 − 20 − 1)
2xx E82ZZ37112B220 5 E82ZZ37112B220 5
E82ZZ37112B200 20 E82ZZ37112B200 20
E82ZZ37112B210 50 E82ZZ37112B210 50
E82xV371K2C 0xx ELN1−0900H005 − 20 − 1)
2xx E82ZZ37112B220 5 E82ZZ37112B220 5
E82ZZ37112B200 20 E82ZZ37112B200 20
E82ZZ37112B210 50 E82ZZ37112B210 50
E82xV551K2C 0xx ELN1−0500H009 − 20 − 1)
2xx E82ZZ75112B220 5 E82ZZ75112B220 5
E82ZZ75112B200 20 E82ZZ75112B200 20
E82ZZ75112B210 50 E82ZZ75112B210 50
E82xV751K2C 0xx ELN1−0500H009 − 20 − 1)
2xx E82ZZ75112B200 20 E82ZZ75112B200 20
E82ZZ75112B210 50 E82ZZ75112B210 50
E82xV152K2C 0xx ELN1−0250H018 − 20 − 1)
2xx E82ZZ22212B200 20 E82ZZ22212B200 20
E82ZZ22212B210 50 E82ZZ22212B210 50
E82xV222K2C 0xx ELN1−0250H018 − 20 − 1)
2xx E82ZZ22212B200 20 E82ZZ22212B200 20
E82ZZ22212B210 50 E82ZZ22212B210 50
1) The motor cable length depends on the inverter type and the switching frequency
