Mechanical installation
Mounting by means of fixing rails
4
l
105 EDK82EV222 DE/EN/FR 13.0
Dimensions [mm]
a b b1 b2 b3 c c1 c2
8200 vector 1 2 3
E82EV251K2C
E82EV371K2C
60
213 243 263 148 120
78 30 63 50
E82EV551KxC
E82EV751KxC
273 303 323 208 180
E82EV152KxC 2)
E82EV222KxC 2)
333
359 2)
363 − 268 240
Dimensions [mm]
d e 1) g k
8200 vector 1 2 3
E82EV251K2C
E82EV371K2C
130 ... 140 120 ... 170 110 ... 200
140
6.5 28
E82EV551KxC
E82EV751KxC
190 ... 200 180 ... 230 170 ... 260
E82EV152KxC 2)
E82EV222KxC 2)
250 ... 260
280...295 3)
240 ... 290 −
140
162 3)
1) If the function module is attached: observe mounting clearance and cable bending radius. The terminals of
function modules in PT design protrude above the housing by 14 mm.
2) Lateral mounting only possible with E82ZJ001 swivel bracket (accessories)
3) With E82ZJ001 swivel bracket (accessories)
