Appendix
Index table
8
l
48 EDSMF2191IB EN 2.0
I−1E40:
EPL IP address
Index
0x1E40
EPL name
NWL_IpAddrTable_0h_REC.Addr_IPAD
Subcode Lenze Values Data type
2 g − U32
3 G −
5 0xC0A864FE −
Access: ro
ƒ Subcode 2:
The subcode contains the IP address of the communication module. It is derived
according to the following rule from the node address (node ID, I−1F93):
W192.168.100.
ƒ Subcode 3:
The subcode contains the IP subnet mask which limits the IP address range that can be
addressed directly (i.e. without using a gateway in the EPL segment of the routers). In
an EPL segment, the subnet mask is permanently assigned to the value
’255.255.255.0’ (0xFFFFFF00).
ƒ Subcode 5:
The subcode contains the IP address of the EPL router via which the EPL segment is
connected to the higher−level network.
The standard entry corresponds to the standard router address of the POWERLINK
specification:
W 192.168.100.254
Permissible entries replace the lowest−order byte of the standard entry with the EPL
address of the node which has the function of a router.
