Appendix
Index table
8
l
41 EDSMF2191IB EN 2.0
How to read the index table
Model of an index table
Index Name
Subcode Lenze Values Data type
Access:
Meaning
Header Meaning
Index Number of the Ethernet POWERLINK index I−xxxx
Name Display text
Leading
columns Meaning
Subcode Number of the subcode
Lenze Lenze setting ("Default" setting) of the code
g
à Display code
The code cannot be configured.
Values Minimum value [smallest increment/unit] Maximum value
In case of a display code the displayed values are specified.
Data type l BITFIELD_8
l BITFIELD_32
l U8 8 bit value without sign
l U16 16 bit value without sign
l U32 32 bit value without sign
l U64 64 bit value without sign
l VS Visible String, string with specified length
Footer Meaning
Access ro: The parameter can only be read (display code)
rw: The parameter can be changed
