background image

Appendix

Index table

8

l

45

EDSMF2191IB EN 2.0

I−1601:
EPL number of RPDO

Index

0x1601

EPL name

PDO_RxMappParam_xxh_AU64.NumberOfEntries

Subcode

Lenze

Values

Data type

0

0

0, 1 ... 32

U64

Access: rw

The object describes the number of valid mapping entries for the PDO channel (n+1).

The value ’0’ inhibits the PDO channel. The sum of all mapping entries enabled via the
objects 0x160x must not exceed the value ’64’.

I−1602:
EPL number of RPDO

Index

0x1602

EPL name

PDO_RxMappParam_xxh_AU64.NumberOfEntries

Subcode

Lenze

Values

Data type

0

0

0, 1 ... 32

U64

Access: rw

The object describes the number of valid mapping entries for the PDO channel (n+1).

The value ’0’ inhibits the PDO channel. The sum of all mapping entries enabled via the
objects 0x160x must not exceed the value ’64’.
